Honeywell Dolphin CT40 Series - N6703 Imager Engine Field of View;Resolution

90 Dolphin CT40 Mobile Computer
Typical Specs
N6703 Imager Engine Field of View/Resolution
DPI can be calculated based on the following formula:
Horizontal DPI = 1280 pixels/width of horizontal field of view (inches)
Vertical DPI = 800 pixels/width of vertical field of view (inches)
Focus Standard Range (SR)
Symbology Near Distance
(in/cm)
Far Distance
(in/cm)
3 mils Code 39 10.6 (4.17) 17.6 (6.93)
5 mils Code 39 7 (2.75) 30.1 (11.85)
10 mils Code 39 2.9 (1.14) 51.7 (20.35)
20 mils Code 39 3.5 (1.38) 80 (31.50)
13 mils 100% UPC-A 3.4 (1.34) 57.3 (22.56)
13 mils 20% UPC-A 7.9 (3.11) 22.8 (8.98)
15 mils C128 3.4 (1.34) 65 (25.59)
10 mils Data Matrix 7.2 (2.83) 29.7 (11.69)
5 mil PDF 417 10.5 (4.13) 18.1 (7.12)
6.7 mil PDF 417 8.4 (3.31) 24.4 (9.61)
6.7 mils QR 10.5 (4.13) 16.9 (6.65)
15 mil QR 2.7 (1.06) 41.4 (16.30)
Focus Standard Range (SR)
Horizontal Field Angle (degrees) 48 ± 2°
Vertical Field Angle (degrees) 31 ± 2°
