Dolphin CT60/CT60 XP Mobile Computer User Guide 109
Typical Specs
S0703 Imager Field of View/Resolution
Note: DPI can be calculated based on the following formula:
Horizontal DPI = 1280 pixels/width of horizontal field of view (inches)
Vertical DPI = 800 pixels/width of vertical field of view (inches)
15 mils QR mm 39 390
in. 1.54 15.35
Focus Standard Range
Symbology Near Distance Far Distance
5 mils Code 39 mm 70 301
in. 2.75 11.85
10 mils Code 39 mm 40 517
in. 1.57 20.35
20 mils Code 39 mm 44 800
in. 1.73 31.50
13 mils UPC-A mm 44 573
in. 1.73 22.56
15 mils Code 128 mm 42 650
in. 1.65 25.59
10 mils Data Matrix mm 72 297
in. 2.83 11.69
6.7 mils PDF417 mm 84 244
in. 3.31 9.61
15 mils QR mm 39 414
in. 1.54 16.30
1
Minimum distance depends on the length of the barcode.
2
Typical code wide to narrow elemental ratio is 3:1. Minimum 100 mils code height of 3 inches.
Focus Standard Range
Symbology Near Distance Far Distance
1
Minimum distance depends on the length of the barcode.
2
Typical code wide to narrow elemental ratio is 3:1. Minimum 100 mils code height of 3 inches.
Focus
Standard Range (SR)/
High Density (HD)
Horizontal Field Angle (degrees) 44 ± 2°
Vertical Field Angle (degrees) 28 ± 2°
