HONEYWELL EMERGENCY NOTIFICATION MANAGER
Table 5. CCS Programming Steps
Table 6. Subsidiary Equipment Programming Steps
4
Create and program an MN
Active Tone.
page 19
5
Create and program a Fire
Active Tone (when Fire is the
highest priority).
page 21
6
Select FNA node in the All Call
list under General II tab
Fig. 16
Subsidiary Equipment
The panels and network annunciators in this section may be
present on an MN network without being part of an ACU, LOC
or CCS. They do not have local control when an MN alarm is
active in the system. They are capable of initiating and
annunciating an MN alarm, but cannot perform acknowledge,
silence, or reset functions while an MN alarm is active in the
system.
Table 6. Subsidiary Equipment Programming Steps
DVC-RPU
MN Paging Levels are not installed when the DVC-RPU acts
as a subsidiary device. Program the DVC-RPU label. Refer to
"DVC-RPU” on page 24.
MN ANNUNCIATOR PROGRAMMING
Program an annunciator as a dedicated MN alarm
annunciator (See page 25). Use XLS-DVC General Zones
Z501 - Z533 to annunciate LOC and ACU paging. Refer to
"XLS-DVC General Zones” on page 26.
Programming
DCC Participation
In a system with both MN and Fire support, DCC must always
be disabled for all XLS120s, XLS140-2s, XLS3000s, XLS-
NCA2s and EBI Workstation.
XLS3000/XLS-NCA2
Panel: In the Panel Settings Menu:
Set DCC Participation to NO to disable DCC Participation.
Fig. 9. Panel Settings Screen (2), XLS3000
Subsidiary Equipment Programming Steps
XLS-DVC
1
Set the MN Mode**
Fig. 15
2
Set the Associated Node
Number field.
Fig. 15
3
Program input categories and
priorities.
Fig. 21
4
Create and program an MN
Active Tone.
page 19
5
Create and program a Fire
Active Tone (when Fire is the
highest priority).
page 21
6
Select FNA node in the All Call
list under General II tab
Fig. 16
**MN paging levels are not installed when the XLS-DVC
acts as a subsidiary device.
Subsidiary Equipment Programming Steps
XLS3000*/XLS-NCA2
Field
Refer to
1
Set the mass notification
priority
page 15
2
Set the DCC field.
page 13
3
Disable Local Control for
XLS3000 in network display
mode, and XLS-NCA2.
page 14
4
Map to MN nodes.(Include the
FNA node in the map).
page 17
5
Program with MN type IDs.
page 18
6
Program with MN Special
Function Zones.
page 19
XLS3000 may be in standard or network display mode.
XLS140-2/XLS120
1
Set the mass notification
priority
page 15
2
Set the DCC field.
page 13
3
Map to MN nodes.
page 17
4
Program with MN type IDs.
page 18
5
Program with MN Special
Function Zones.
page 19
