Enhanced Micro TDC 3000 User’s Manual 5-31 9/95
5.4.3
• ADJUST button
When you press the “+” button in the Adjustment mode of MODE 1 and MODE 2,
the screen image changes as follows.
WIDTH : Horizontal display width becomes wider.
H. CENT : Display center shifts to the right.
HEIGHT : Vertical display height becomes taller.
V. CENT : Display center shifts upward.
MODE 1 SPC (side pinchushion) : Vertical edges barrel out.
ROTATION : Display rotates clockwise. (Only
available for HM-4821-D)
MOIRE : Moire pattern is changed.
COLOR Temperature : Color temperature changes to
operator adjusted color temperature.
R : Red of Color temperature No. 3 becomes strong.
MODE 2 G : Green of Color temperature No. 3 becomes strong.
B : Blue of Color temperature No. 3 becomes strong.
When you press the “-” button in the Adjustment mode, the screen image changes
as follows.
WIDTH : Horizontal display width becomes narrower.
H. CENT : Display center shifts to the left.
HEIGHT : Vertical display height becomes shorter.
V. CENT : Display center shifts downward.
MODE 1 SPC (side pinchushion) : Vertical edges barrel in.
ROTATION : Display rotates counterclockwise. (Only
available for HM-4821-D)
MOIRE : Moire pattern is changed.
COLOR Temperature : Color temperature changes to
color temperature No. 1.
R : Red of Color temperature No. 3 becomes weak.
MODE 2 G : Green of Color temperature No. 3 becomes weak.
B : Blue of Color temperature No. 3 becomes weak.
NOTE: When you adjust MOIRE, moire pattern may be reduced. (It depends on the
preset timing.)
If you compensate MOIRE excessively, horizontal jitter may appear on the picture.
(It depends on timing.)
When you adjust MOIRE, adjust so horizontal jitter does not appear on the picture.
