Enhanced Micro TDC 3000 User’s Manual 5-33 9/95
5.4.3
• COLOR Temperature indicator
See DISPLAY SETTING, subsection 5.4.3.3.
• WIDTH indicator
The WIDTH indicator lights up, when you select WIDTH in MODE 1.
53933
RGB123
COLOR
WIDTH Indicator Lights Up
• H. CENT indicator
The H. CENT indicator lights up, when you select the H. CENT in selecting
MODE 1.
53934
RGB12 3
COLOR
H. CENT Indicator Lights Up
• HEIGHT indicator
The HEIGHT indicator lights up, when you select HEIGHT in MODE 1.
R
GB12 3
COLOR
HEIGHT Indicator Lights Up
53935
