Enhanced Micro TDC 3000 User’s Manual 5-34 9/95
5.4.3
• V. CENT indicator (MODE 1)
RED indicator (MODE 2)
- The V. CENT indicator lights up, when you select V. CENT in MODE 1.
- The RED indicator lights up, when you select RED in MODE 2.
RGB12 3
COLOR
V. CENT (RED) Indicator Lights Up
53936
• SPC indicator (MODE 1)
GREEN indicator (MODE 2)
- The SPC indicator lights up, when you select SPC in MODE 1.
- The GREEN indicator lights up, when you select GREEN in MODE 2.
53937
RGB123
COLOR
SPC (GREEN) Indicator Lights Up
• ROTATION indicator (MODE 1) (Only available for HM-4821-D)
BLUE indicator (MODE 2)
- The ROTATION indicator lights up, when you select ROTATION in MODE 1.
- The BLUE indicator lights up, when you select BLUE in MODE 2.
53938
RGB12 3
COLOR
ROTATION (BLUE) Indicator Lights Up
RGB12 3
