Enhanced Micro TDC 3000 User’s Manual 2-11 9/95
2.7.2
53386
BUS A BUS B
Figure 2-8 — TP-485-3 I/O Face Plate
53360
BAR CODE
ASSY NO.
51304766-300
REV D
J2J1
TP485
Figure 2-9 — TP-485-3 I/O Board
