Extinguishing Control Computer 8010 - Series 2
64 FB 798352 / 11.07
12.1 Single Zone display
The status of the corresponding zone or of the output is shown with the 13 LED. The status of the 13 zones is
shown in normal operation.
With the key >Switchover<, it is possible to switch between indicating the zones or outputs.
Detector zone
Fire/Switch off/Trouble
12345678
9 10111213
Fig. 2: Zone displays
12.1.1 Status display of the zones
Detector zone no. 1 to no. 9 (yellow/red LED)
Off
Î
Normal operation, Detector zone ready to signal
Lights up red
Î
Fire alarm of the detector zone no. 1 to 9
Flashes red
Î
First alarm indicator, the first alarm was triggered by this zone
Flashes yellow/red
Î
Test mode
Flashes yellow
Î
Trouble, only restricted alarm readiness of the detector zone
On - yellow
Î
Switch-off, the detector zone is switched off via the control panel
Twinkle yellow
Î
Input monitor, the zone number was entered via the control panel keypad
