Honeywell Esser 8010 - 12.5 Multisector-Control Setup

Extinguishing Control Computer 8010 - Series 2
76 FB 798352 / 11.07
13 Control indicator and Alarm counter (Option)
The Extinguishing Control Computer can be equipped with an optional >Control indicator and Alarm counter<
(Part No. 788016).
The LED indicators lit when the corresponding output is activated. Each of the 13 output has an assigned LED
indicator. The description of each output can be edited in the lettering area.
Alarm counter
Relay (AE) 1
2
0 0 0 5
3
4
5
6
7
8
9
10
11
12
13
Fig. 17: Control indicator and Alarm counter (Part No. 788016)
The mechanical alarm counter displays the total quantity of all recognized fire alarms and is incremented with
each new fire alarm. Resetting the counter to zero - 0000 - is not possible.
