FireLite SLC Wiring Manual — P/N 51309:R3 7/29/2019
23
Fault Isolator Devices SLC Circuits with Isolators
The figure below shows typical wiring of an ISO-6 Isolator Module:
ISOLATOR 1
ISOLATOR 2
ISOLATOR 3 ISOLATOR 4
ISOLATOR 5
ISOLATOR 6
iso-6wire.wmf
SLC in from FACP
or previous device
Figure 4.2 Wiring an ISO-6 Module
SLC out to
next device
status indicators
+
-
+
-
