FireLite SLC Wiring Manual — P/N 51309:R3 7/29/2019 71
MDF-300 Terminal Conversion Charts for New & Legacy Devices
C.4 MDF-300
8
9
10
11
12
13
14
15
0
1
2
3
4
5
6
7
TENS
LOOP
LOOP ADDRESS
ADDRESS
8
9
7
6
5
9
8
7
6
5
0
1
2
3
4
4
3
2
1
0
TENS
8
9
10
11
12
13
14
15
0
1
2
3
4
5
6
7
ONES
ONES
0
2
4
6
8
0
2
4
6
8
Newer Module
(H-Type)
Address +1 (H) -
Address +1 (H) +
Base Address (L) +
Base Address (L) -
SLC -
SLC +
SLC -
SLC +
Address +1 (H) -
Address +1 (H) +
Base Address (L) +
Base Address (L) -
Legacy Module
(V-Type)
Legacy Module Terminal Number
(V-Type)
Terminal Function
Newer Module Terminal Number
(H-Type)
1SLC - 1
2SLC + 2
3 Unused 3
4 Unused 4
5 Unused 5
6 Base Address (L) - 6
7 Base Address (L) + 7
8 Address +1 (H) + 8
9 Address +1 (H) - 9
N/A Unused 10
N/A Unused 11
Table C.4 MDF-300 Terminal Conversions
