Galaxy Programming Manual
1
Quick Setup
Section 1: Quick Setup
To quickly set up the Galaxy control panel for programming follow these simple steps:
1. Connect a 1k Ω (1%) resistor across each of the zones on the panel and RIO (if connected).
2. Ensure that the tamper return loop — the terminal marked as
T on the PCB — is a complete loop.
NOTE: This is factory set as a completed loop with a 0 V return.
3. Connect a keypad to the AB LINE terminals on the control panel. The Galaxy 128 has two AB lines.
The Galaxy 500, 504 and 512 have four AB LINE terminals. Connect the terminals as follows:
Table 1. Terminal Connections
4. Connect a 680 Ω End Of Line (EOL) resistor across the A and B terminals of the keypad.
5. Ensure that the keypad is fitted to the wall (see Installation Manual, II1-0030, Keypad
Installation Procedure, Section 4).
6. Connect the battery before replacing the control panel lid.
7. Make sure that the backup battery switch on the PCB (MEM BK) is closed.
8. Connect the mains wiring to the control panel. Do not switch the mains ON.
9. Replace the control panel lid and secure the fastening screw.
10. Switch on the mains voltage (230 Va.c. / 50 Hz).
11. The following sequence of events occur:
• the keypad buzzer and control panel horn (if fitted) activate momentarily,
• flashing ✷✷✷✷✷✷✷✷✷✷✷✷✷✷✷✷ is displayed on the keypad,
• the sounders stop and the keypad displays become blank,
• the green power LED lights,
• the default banner is displayed on the keypad.
12. The system is now ready to be programmed. Refer to Section 2: System Operation for
programming details.
lenaPlortnoCdapyeK
BB
AA
++
--
GALAXY <Panel T
ype> <Panel V
ersion>
00:00 SUN 01 JAN
