Galaxy Flex Installer Manual Program Outputs [53]
109
Zone Function
Output Functions
RF
Jam
RF Super Bell Fail Fault Bell
Test
Comms
Test
Listen–in
66 67 68 76 77 78 81
01 Final – – – – – – –
02 Exit – – – – – – –
03 Intruder – – – – – – ?
05 Security – – – – – – –
07 Entry – – – – – – –
08 Push Set – – – – – – –
09 Keyswitch – – – – – – –
10 Secure Final – – – – – – –
11 Part Final – – – – – – –
12 Part Entry – – – – – – –
13 PA – – – – – – ?
14 PA Silent – – – – – – ?
15 PA Delay – – – – – – ?
16 PA Delay Silent – – – – – – ?
18 Spare – – – – – – –
19 Fire – – – – – – ?
20 Tamper – – – – – – –
22 Beam Pair – – – – – – –
23 Battery Low – – – A – – –
24 Line Fail – – – A – – –
25 AC Fail – – – A – – –
26 Log – – – – – – –
28 Video – – – – – – –
29 Video Exit – – – – – – –
32 Set Log – – – – – – –
33 Custom-A ? ? ? – – – –
34 Custom-B ? ? ? – – – –
39 Keyswitch Reset – – – – – – –
40 Bell Fail – – A A – – –
41 Intr Low – – – – – – ?
42 Intr High – – – – – – ?
43 PSU Fault – – – A – – –
44 Fault – – – A – – –
Key:
S Activates when system is Set ? Activation dependant on system programming
P Activates when system is Part Set X Activates during Exit Time
U Unset E Activates during Entry Time
A Activated in any condition L Switches output off if linked to destination output
– No effect T Activates if zone resistance is less than value for
tamper s/c or greater than value for tamper o/c
O Activates when zone is omitted
