Galaxy Flex Installer Manual Appendix D: Specifications
207
Appendix D: Specifications
Mechanical
Panel enclosure width: 337 mm
height: 333 mm
depth: 93 mm
weight: 1.8 kg, excluding battery and in-box peripherals
Maximum battery size 151 x 65 x 115 mm
Battery capacities 4 Ah Yuasa
7 Ah Yuasa
9 Ah Yuasa Yucel
10 Ah Yuasa
Operating temperature −10°C to + 55°C
Humidity 0 to 85%
Electrical
Mains input 230 V (+10%, −15%) @ 50Hz
Control panel current consumption 120 mA maximum
Power supply Type A
Battery type Sealed lead-acid, plastic enclosure
Max ripple voltage ≤ 150 mV pk-pk
Maximum auxiliary current rating 0.9 A
EN grade 2 maximum auxiliary current rating 0.7 A
Minimum standby battery capacity required for
maximum load (EN50131/PD6662 @ 12 hrs)
8.4 Ah
Maximum Battery Size 10Ah
Time to recharge Battery to 80% 10Ah Battery: 67 hrs
Total PSU output 1 A
Aux voltage output 13.8 V nominal (10 V to 14.5 V)
APS fault 10.7 V nominal
Switched outputs:
Output 1 400 mA maximum sink current
Output 2 400 mA maximum sink current
Output 3 (speaker) 8 to 32 ohms
PTC ratings:
AUX1 1.1 A
BATT 3 A
Data retention 10 years @ 150 deg. C
