Appendix G: Peripherals Galaxy Flex Installer Manual
214
Wiring
Connect the keypad to the RS485 data bus. Refer to the wiring instructions supplied with the
keypad.
Configuration
Once wiring is complete and the Auto Detect procedure has been followed, or following an
Engineer Exit, the keypad displays 1 MOD ADDED – Esc TO CONTINUE.
Restart the system or exit engineer mode. The system automatically recognises the new
module.
Volume control
Some models of keypad are fitted with a volume control switch marked VOL at the bottom
right-hand corner of the PCB. Make sure the keypad/KeyProx is powered up and adjust to
the desired volume for buzzer functions. Refer to Appendix F for keypad/KeyProx part
numbers with the volume control function.
Self diagnostics
Use this feature to test the keypad inputs and outputs.
To start the test, disconnect the power to the keypad. Press and hold ent, and then re-apply
the power. The test routine starts immediately. Each test last approximately four seconds.
To stop the test, disconnect the power.
Keypad/KeyProx operation
Number keys Used to enter access codes and to select and modify programming
options.
View keys (A and B) Used to set the system in conjunction with a PIN, and also used to
scroll through menu options.
Enter key (ent) Used to access menu option and to confirm programming options.
Escape key (esc) Used to cancel modifications made to an option, and to return to a
previous option level. Esc can also be used to abort the setting
routine.
