Galaxy Flex Installer Manual Appendix G: Peripherals
235
Specifications
Based on 34 Ah battery and UK grade 3 compliance.
Input voltage
Output voltage (nominal)
Output current (max)
Operating temperature
230 V a.c. (+10%/-15%) @ 50 Hz
13.8 V and 14.5 V
3.0 A
-10 deg C to +50 deg C
Aux1 & Aux2
Output voltage (nominal)
Output current (max)
13.8 V
0.75 A each
14.5 V Output (French variant
only)
Output voltage (nominal)
Output current (max)
14.5 V
0.15 A (when using this current, the AUX1 & AUX2
currents will be reduced by an equivalent amount).
Battery charge current (max)
Maximum ripple voltage
1.4 A
<100 mV
Fuses
F1 (14.5 V)
F2 (Battery)
F3 (12 V Aux1)
F4 (12 V Aux2)
500 mA – 20 mm anti-surge
1.6 A – 20 mm anti-surge
1.0 A – 20 mm anti-surge
1.0 A – 20 mm anti-surge
EN50131 Compliance
This product is suitable for use in systems designed to comply with EN50131-6 and
PD6662:2004.
Security Grade - 3
Environmental Class - II
Power Supply Type - A
