Access Doors [25] Galaxy Flex Installer Manual
46
HH:MM_XXXXXXXXXX_USR_NNN_UUUUUU_MYY_–_ (39 character display)
Key:
HH:MM = time in hour:minutes (5 characters). The date will be printed only at the
beginning of every day, starting at midnight.
XXXXXXXXXX = access message (up to 10 characters) Valid, Invalid Card, Reject Card
USR = User
NNN = User number to which MAX card is assigned
UUUUUU = User descriptor (up to 6 characters)
M = MAX reader address
YY = MAX physical address
– = unused character slot
_ (underscore) = this represents a space and is not printed or displayed in the access log.
For example: A valid card read at MAX
4
30 from the card held by user 020, name Albert, at
13:48 would be:
13:48 Valid USR 020 Albert M30 –
MAX Log
The Flex 100 system has a 1000-event log for recording MAX activations. This log is shared
by all readers on the system and operates on a FIFO (First In, First Out) basis when full.
To display the events in the MAX log, select Access Doors [25], select the required MAX
address, and then press ent.
The first event that occurred on the selected MAX is displayed along with details of the
time, date and MAX number. Press A or B to scroll through the events.
Press # for additional information:
Note: See Appendix B for MAX Event Log Messages.
MAX events print out
To print MAX events as they occur, enable the Online Print [51.28] option, and ensure a
printer, which remains online at all times, is connected to the panel.
Use the Online Level [51.29] option to select the level of detail to print.
02:25 SUN 26 OCT
USR032 Valid
READER01 Grp A1
Reject Grp Set
event type MAX user number
time and date
of event
