Description
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  11
Thedetailsonthetypeplatehavethefollowingmeaning:
Figure No. Meaning
1 Modelname
2 Manufacturer
3 Nominalsize
4 ANSIclass
5 Temperaturerange
6 Maximumallowablepressure
7 Manufacturingdate
8 Directive
9 Fluidgroup
10 CEmarking
11
Inconformitywithstandard,e.g.,DINEN
334 
12 CustomerrevisionNo.
13 Manufacturingdate(year)
14 Pressurerating
15 Installationlength
16 Serialnumberofthedevice
17 Defaultposition(open/closed)
18 Typeofpilot

Thenameplatecanbefoundinthelocationshownbelow:
Figure No. Description
1 Frontofthepilot

Interpretingthetype
plateoftheactuator
assembly
Locatingthetypeplateof
thepilot
