Honeywell HON P095NG Series - Maintaining the HON P095 NG-MP Pilot

Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  65
Figure Step Description
45
Screwthelocknut(1)backinplaceallthe
way.
46
Screwthesetscrew(1),includingthehex
nut,backin.
47 Screwthecap(1)backon.

Proceedasfollows:
 Maintainingtheadjustablerestrictor(seepage75)
 Completingthemaintenance(seepage76)
 Maintainingtheactuatorassembly(seepage50)
 Storingthedevice(seepage78)


8.5.2 MaintainingtheHONP095NG‐MPpilot

Crushandimpacthazardposedbycomponentsfallingortopplingoveraccidentally.
Whenworkingwithheavycomponentsthathavebeenremovedorareyettobeinstalled,
injurymayresultifthecomponentsstartmovinginanuncontrolledmanner,e.g.,fall down
fromtheworkingsurfaceortoppleover.
 Placeremovedcomponentsexclusivelyonlevel,horizontalworkingsurfaceswithenough
load‐bearingcapacity.
 Ifnecessary,secureremovedcomponentssothattheywillnotfallortoppleover.
 Weartherequiredpersonalprotectiveequipment.
 Exercisecautionwhenperformingtherelevanttasks.

Nexttask
Fallingcomponents
