Adjustingthesettingsofthedevice
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  40
6 Adjustingthesettingsofthedevice

Topic Page
Settingthetargetpressure 40

6.1 Settingthetargetpressure
Thefollowingsectionsshowhowthegaspressureregulator’soperatingpressurecanbe
adjustedwiththepilotsetscrewaftercommissioninghasbeencompleted.
Foradjustmentsduringcommissioning,pleaserefertoStartingupthegaspressureregulator
(seepage37).

 Thesystemispressurizedwiththeoperatingpressure.
 Apressuregaugeisconnectedinfrontoftheoutletvalve.

Proceedasfollows:
Figure Step Description
1 Unscrewthecap(1).
2
Loosenthelocknutofthesetscrew(1).
Important!Makesurethatthesetscrew
doesnotturnasyouloosenthenut!
3a
Toraisetheoperatingpressure,screwthe
setscrewin.Adjustthescrewpositionuntil
theoperatingpressureyouwantis
reached.
Contents
Pressuresetpointad‐
justments
Requirements
Settingthetargetpres‐
sure
