Description
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  13
Actuatorassemblyconfiguration:
Figure No. Description
1 Dome
2 Diaphragmunit
3 Movingparts
4 Valvehousing
5 Bottomcover

Theparts(3)thatmovewiththediaphragmunit(2)areshownindarkgray.

Figure Color Meaning
Inletpressure
Outletpressure

Motorizationpressure

Actuatorassemblycon‐
figuration
Actuatorassemblypres‐
suresections
