Performance Series HQA Digital Video Recorder Local User Guide
140
2. Refer to the following table to interpret the HDD information:
SATA
o indicates the current HDD is normal.
x indicates there is an error.
- indicates that there is no HDD.
? indicates that a HDD is damaged.
Type Indicates the HDD type (for example, Read/Write).
Total Space Indicates the total capacity of the HDD.
Free Space Indicates the amount of free space remaining on the HDD.
Status Indicates the operating status of the HDD.
S.M.A.R.T.
Indicates S.M.A.R.T (Self-Monitoring, Analysis, and Reporting
Technology) status.
3. In the list of HDDs, double-click an HDD to view more details.
Figure 13-2
4. Right-click to return to the previous screen.
Viewing Recording Information
To view recording information
Go to Main Menu Info System Record Info.
