Owner’s Guide 400-305-000-EFS
8
ENGLISH
The controller provides 3 backlight modes. Depending on the mode selected, the screen behaves as
follows:
• Scrn Off: The screen is not lit (the backlight is off).
• Scrn On HI: The screen is lit at high intensity.
• Scrn On LO: The screen is lit at low intensity (default mode).
When you press any button, the screen is lit at high intensity for 8 seconds.
Set the Backlight mode
Set Backlight
(2 times)
(2 times)
Press the main but-
ton for 3 seconds at
any time (or do not
press any button for
60 seconds) to save
any changes you
have made and exit
the setup menu.
To set the backlight
mode, press the
main button for 3
seconds to display
the setup menu and
proceed as shown:
400-305-000-B (69-2316EFS-03).book Page 8 Monday, September 28, 2009 11:06 AM
To Next Page
