|53
10.1.5 Wiring AC-DC Power for Zone2
230V AC/12-15V ADJ POWER SUPPLY WITH 7Ah BATTERY
Figure 10-7: Electrical Wiring - 230V AC TO 12-15V DC ADJUSTABLE POWER SUPPLY WITH 7Ah
BATTERY
10 Reference Drawings
