Honeywell Notifier ID50 - Appendix 4 - EN54-2 Options with Requirements

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Appendix 4 - EN54-2 Options with Requirements
A4 - 1 997-263-000-11, Issue 11
January 2010
Appendix 4
EN54-2- Options with Requirements
In addition to satisfying the requirements of EN54-2
Options with Requirements, the table below defines
whether the CIE is configurable in accordance with the
mandatory or optional requirements of VdS 2540.
EN54-2 Description VdS 2540 C.I.E.
Option Option Configurable?
INDICATIONS
7.10.4 Fault signal from fire protection equipment Required Yes
7.13 Alarm counter Required Yes
8.3 Fault signals from points Optional Yes
8.4 Total loss of power supply Optional No
CONTROLS
7.11.1 Delays to outputs Optional Yes
7.11.2 Manual or automatic switching of delays to outputs Optional Yes
7.12.1 Dependency on more than one alarm signal: Type A Optional No
7.12.2 Dependency on more than one alarm signal: Type B Required Yes
7.12.3 Dependency on more than one alarm signal: Type C Prohibited No
9.5 Disablement of each address point Optional Yes
10 Test condition Required Yes
OUTPUTS
7.8 Fire alarm device(s) Required Yes
7.9.1 Fire alarm routing equipment Required Yes
7.9.2 Fire alarm routing equipment with alarm confirmation Required Yes
7.10.1 Automatic fire protection equipment: Type A Optional Yes
7.10.2 Automatic fire protection equipment: Type B Optional No
7.10.3 Automatic fire protection equipment: Type C Required Yes
8.9 Fault warning routing equipment Required Yes
11 Standardized I/O interface Required Yes
1
1
Interface meets VdS 2540 which requires DIN 14675 & 4662, but not full EN54-2, 11.
A1 Fault Signal From CIE
This is a VdS 2540 requirement. The CIE provides for
this EN54-2 option.
The CIE comprises a volt-free contact relay configured
as a dedicated fault output. Refer to Section 4.4.5
Configuration Outputs C and D and Section 5.6.3 On-
board Circuits for more details.
A2 Alarm Counter
This is a VdS 2540 requirement. The CIE can record a
maximum number of 9,999 alarm events. If this limit is
reached the alarm counter will automatically reset to zero.
It is not possible to reset the counter through the CIE,
except at access level 4.
A3 Fault Signals from Points
This is an optional VdS 2540 requirement. The CIE will
display fault signals from individual sensors and devices.
