RS485 Serial connection
 The connection of LDC6000N with the control panel use serial line RS485.
 RS-485 line must be installed in “MULTI-POINT” configuration (daisy chain).
 Each peripheral must be programmed with an address between 1  16. (refer to TAB.1).
“Multi-Point” configuration (Daisy Chain)
Connect two wires to the RS485
control panel terminal block
(LIN+ and LIN- ) to the
corresponding terminals of the
first device on the line.
Continue wiring from the first
device to the next, and so on.
Install EOL (120-150,0.5W) on
the terminal block on both
control panel and last device of
the line.
Maximum length between control
panel and last device 1,5 km.
Use shielded cable with
appropriate section type
Belden 9574 or 9575
AM-2000
13
EOL= 120 
12
7
EOL= 120 
2322
LCD-6000N
1 2
3
4
5
GND+24
V
LCD-6000N
1 2
3
4 5
AM-4000
17
EOL= 120

16
11
EOL= 120 
3130
LCD-6000N
1
2
3
4
5
GND+24
V
LCD-6000N
1 2
3
4
5
AM-6000
09
EOL= 120 
087
EOL= 120 
2 1
LCD-6000N
1 2
3
4
5
GND+24
V
CN
C
N
LCD-6000N
1 2
3
4 5
Typical wiring RS485 with 24Vdc power supply in common
(Control panel user output voltage 24Vdc)
