Honeywell Notifier LCD6000N User Manual

LCD6000N Installation Manual PAGE - 13
LCD6000N_manu-inst Doc. M-183.1-LCD6000N-ENG Rev A.2 NOTIFIER ITALIA
CN1 Terminal block
N°
Terminal
block
Description Note
5
LIN –
RS 485 Serial line
4 GND
Negative reference for serial line RS 485*
3 LIN +
RS 485 Serial line
2 GND
Power input
1 + 24Vdc
* TO BE USED IN CASE OF POWER NOT COMMON WITH THE CONTROL PANEL.
ENVIRONMENTAL FEATURES
Operative temperature: - 5°C ÷ + 40°C.
Humidity: 10% ÷ 93% (without condensate).
Stock temperature: -10°C - + 50° C.
Weight: 0,54Kg
Power supply
Voltage range: 10÷30Vdc.
Current in normal condition (without fault or alarms) with display off: 30mA
Current in alarm condition (with fault or alarms) with display on and buzzer active: 81mA

Honeywell Notifier LCD6000N Specifications

General

Brand	Honeywell
Model	Notifier LCD6000N
Category	Control Panel
Language	English
