Honeywell Notifier LCD6000N - Technical Specifications; Topographic Board Layout

PAGE - 12 Installation Manual LCD6000N
NOTIFIER ITALIA Doc. M-183.1-LCD6000N-ENG Rev A.2 LCD6000N_manu
Topographic LDC6000N board
Cables specifications
Up to 1.200 mt. 18 AWG Belden 9574 type
Up to 1.500 mt. 16 AWG Belden 9575 type
1
2
34
5
CN1 Terminal block
CNT terminal
block for front
keypad
Buzzer
