70 NFS2-3030 Listing Document — P/N LS10006-051NF-E:F2 5/19/2022

LCD-80* Annunciator O O O O O O O O O O

LCD2-80* Annunciator O O O O O O O O O O

RPT-W* Repeater Wire O O O O O O O O O O

RPT-F* Repeater Fiber O O O O O O O O O O

RPT-485W* Repeater Wire O O O O O O O O O O

RPT-485FW* Repeater Wire/Fiber O O O O O O O O O O

FFT-7* Firefighter’s Telephone O O(5) O O O O O O O O

FFT-7S* Firefighter’s Telephone O O(5) O O O O O O O O

FHS* Fireman’s Handset O O(5) O O O O O O O O

FPJ* Fireman’s Phone Jack O O(5) O O O O O O O O

NBG-12LX* Addressable Manual Pull Station O O O O O O O O O O

NBG-12LRA* Agent Release Abort Station O O O O O O O O O O

RM-1, RM-1SA* Remote Microphone O(5) O O O O O O O O O

BP2-4 Battery Plate Y Y Y Y Y Y Y Y Y Y

FCO-851 Fire/CO Detector O O O O O O O O O O

FSA-8000 Intelligent Aspiration Detector O O O O O O O O O O

FSA-20000 Intelligent Aspiration Detector O O O O O O O O O O

FSA-5000 Intelligent Aspiration Detector O O O O O O O O O O

FSA-20000P Intelligent Aspiration Detector O O O O O O O O O O

CGW-MB CLSS Gateway Main Board Y(8,9) N N N N N N N N N

HON-CGW-MBB CLSS Gateway in Plastic Enclosure Y(8,9) N N N N N N N N N

CGW-PT CLSS POTS Board Y(8,9) N N N O N N N O Y(8)

CGW-BB CLSS Dialer Enclosure Y(10) O(10) N N N N N N O(8) Y(10)

CGW-DACT CLSS Dialer (CGW-MB with CGW-PT) Y(8,9) N N N O N N N O Y(8)

CGW-DACT-CH CLSS Dialer Chassis Y(8,9) N N O N N O N N Y

HON-CGW-DACT CLSS Dialer in Plastic Enclosure Y(8,9) N N N O N N N O Y(8)

CCM-ATT-HON AT&T Cellular Module O O N N N N N N O O

CCM-VZ-HON Verizon Cellular Module O O N N N N N N O O

HWF2A-COM IP Digital Alarm Communicator Y(8,9) N N N O N N N O O(8)

HWF2V-COM IP Digital Alarm communicator Y(8,9) N N N O N N N O O(8)

KEY:

* - Modules are listed separately Y - Yes N - No O - Optional X - Not permitted for security applications

NOTES:

1. Non-emergency

2. Emergency

3. At least one power supply must be utilized.

4. The system must contain one of these units.

5. When configured for Emergency Relocation and Evacuation Equipment, the system must meet Local configuration with a minimum of one amplifier, one

Audio Message Generator, one Voice Control Module. The phones, remote microphones, and audio coupling transformers are optional. (Voice Alarm

System Manual, Part No. 51252, shown in File S635, Vol. 5C, ILL. 1)

6. One of the cab enclosures must be utilized.

7. Various dress panels/dead fronts/trim rings must be employed so that internal components and high voltage is not accessible.

8. Also required when devices for Carbon Monoxide signaling are employed

• When configured for Smoke Control Service, system must be configured for Local service and with utilization of the separately listed models BGRA-SCS,

BRB-SCS, CEF-SCS, RSA-SCS, RSB-SCS, RSC-SCS, RSD-SCS, or RSE-SCS firefighter’s smoke control stations. (Smoke Control System Manual, Part

No. 15712, as shown in UL File S5511, Vol. 1, ILL. 1)

• When configured for security applications, system must be configured for a maximum of 60 seconds for Entry/Exit delay. Standby power must provide 24

hours of standby. Not suitable for Canadian (ULC) applications.

• CPU2-3030ND is utilized when a large system is configured. CPU2-3030ND allows for connections of additional devices which interface with the CPU2-

3030D on a sizable system.

9. Required if utilizing a central station other than supported by CGW-MB

• Alarm verification (maximum verification period of 60 for field programmable between 0 and 60s)

• Supports standard 2-wire smoke detectors using Models FZM-1. refer to the Device Compatibility Document for compatible 2-wire smoke detectors

• Supports addressable or analog devices

• Field Programming

• Signal Silence Inhibit

• Remote annunciator outputs

• Automatic Alarm Signal Silence

• Drift compensation
