NFS2-3030 Listing Document — P/N LS10006-051NF-E:F2 5/19/2022 73
ACT-25 Audio Coupling Transformer O(5) O O O O O
ACT-70 Audio Coupling Transformer O(5) O O O O O
RM-1, RM-1SA Remote Microphone O(5) O O O O O
XPIQ Quad Intelligent Audio Transponder O O O O O O
XPM-8L Transponder Monitor Module O O O O O O
AVL-1 Audio Voice Link O O O O O O
PRN-6 Printer O O O O O O
PRN-7 Printer O O O O O O
VS4095 Keltron Remote Printer O O O O O O
CRT-2 Display Terminal O O O O O O
NCS5-W-ONYX, NCS5-W-ONYX Network Control Station O O O O O O
LCD-80 Annunciator O O O O O O
LCD-160/C Annunciator O O O O O O
AKS-1B Annunciator Key switch O O O O O O
DPI-232 Panel Interface O O O O O O
NCM-W/F Network Control Module O O O O O O
HS-NCMW/MF/SF/WMF/WSF/MFSF/W-2/
WMF-2/WSF-2
High Speed Network Control Module O O O O O O
NBG-12LX Addressable Manual Pull Station O O O O O O
BP2-4 Battery Plate Y Y Y Y Y Y
FSA-8000A Intelligent Aspiration Detector O O O O O O
FSA-20000A Intelligent Aspiration Detector O O O O O O
FSA-5000A Intelligent Aspiration Detector O O O O O O
FSA-20000P Intelligent Aspiration Detector O O O O O O
KEY:
* - Modules are listed separately Y - Yes N - No O - Optional
NOTES:
1. At least one power supply must be utilized.
2. The system must contain one of these units.
3. One of the cab enclosures must be utilized.
4. Various dress panels/dead fronts/trim rings must be employed so that internal components and high voltage is not accessible.
5. When configured for Emergency Relocation and Evacuation Equipment, the system must meet Local configuration with a minimum of
one amplifier, one Audio Message Generator, one Voice Control Module. The phones, remote microphones, and audio coupling
transformers are optional. (Voice Alarm System Manual, Part No. 51252, shown in File S635, Vol. 5C, ILL. 1)
• When configured for Smoke Control Service, system must be configured for Local service and with utilization of the separately listed
models BGRA-SCS, BRB-SCS, CEF-SCS, RSA-SCS, RSB-SCS, RSC-SCS, RSD-SCS, or RSE-SCS firefighter’s smoke control stations.
(Smoke Control System Manual, Part No. 15712, as shown in UL File S5511, Vol. 1, ILL. 1)
• When configured for security applications, system must be configured for a maximum of 60 seconds for Entry/Exit delay. Standby power
must provide 24 hours of standby. Not suitable for Canadian (ULC) applications.
• CPU2-3030ND is utilized when a large system is configured. CPU2-3030ND allows for connections of additional devices which interface
with the CPU2-3030D on a sizable system.
ULC Type Service Model IDC Class
Initiating
Device Types
NAC
Type
Signaling
Data Communication Link
Local NFS2-3030
NFS2-3030E
Class A
Class B
A, M, WF, SS Class A
Class B
C(1), NC DCLB, DCLA, DCLR
Auxiliary NFS2-3030
NFS2-3030E
Class A
Class B
A, M, WF Class A
Class B
N/A DCLB, DCLA, DCLR
Remote Station (PPU) NFS2-3030
NFS2-3030E
Class A
Class B
A, M, WF, SS Class A
Class B
DACT,
Rev. Pol.,
OT (1)
DCLB, DCLA, DCLR
Proprietary (PPU) NFS2-3030
NFS2-3030E
Class A
Class B
N/A Class A
Class B
NC DCLB, DCLA, DCLR
Proprietary (Rec. Unit) NFS2-3030
NFS2-3030E
Class A
Class B
N/A Class A
Class B
MX DCLB, DCLA, DCLR
Smoke Control NFS2-3030
NFS2-3030E
Class A
Class B
A, M, WF, SS Class A
Class B
N/A DCLB, DCLA, DCLR
1. Requires separately listed equipment
Table 14 ULC Type of Service Configurations
Module Description Local AUX RS P (PPU) *REL *P Rec
Table 13 System Configuration for ULC Requirements (3 of 3)
