Smoke Detector Read Status
Line 6 - Line 6 displays two statistics that display for inputs (detectors and modules) and zones; in
the above example they are:
AUTOMATIC INACTIVE
The first field displays the point control. There are three designations that could appear in this
field
The second field displays the point status. There are three designations that could appear in this
field.
The device is a detector (an input device) so by referring to the descriptions below, it can be
determined that the point is in a normal state.
Inputs: (detectors, monitor modules, zones)
If the point is not in trouble or disabled, and the point is automatically controlled by the panel, the
display will be one of the following:
AUTOMATIC INACTIVE
AUTOMATIC ACTIVE
AUTOMATIC PREALARM
If the point is disabled, the display will be one of the following. The Trouble Status field will
appear if the point is in trouble.
DISABLED INACTIVE <Trouble Status>*
DISABLED ACTIVE <Trouble Status>*
DISABLED PREALARM <Trouble Status>*
If the point is in trouble, the display will read:
TROUBLE INACTIVE <Trouble Status>*
TROUBLE ACTIVE <Trouble Status>*
TROUBLE PREALARM <Trouble Status>*
*The field <Trouble Status> will contain one of the device trouble messages listed in Table 2.1,
“Point (Device) Troubles,” on page 28.
Line 7 - The custom label for this point.
Line 8 - Continuation of the point’s custom label, first zone, and device type.
Lines 9,10 - a display of all the zones that contain the current point being read. These lines will
have values in them only if the device is a detector.
Lines 11 through 14 - These lines display only if the device being read is a smoke or heat detector.
Refer to Section 1.8.2, “More Information”, on page 17 for an explanation of these fields.
Line 16 -
BACK - Press to return to the previous screen.
Point Control
Designation
Description
AUTOMATIC The point is being controlled automatically by the panel.
DISABLED The point has been disabled by an outside source.
TROUBLE The point is in a trouble state and is no longer functioning automatically.
Point Status
Designation
Description
INACTIVE The point is currently reporting no events.
ACTIVE The point is currently in an off-normal status.
PRE-ALARM The point is currently in a prealarm status.
