NFS2-3030 Operations Manual — P/N 52546:A 11/29/2005 45
Logic Zone Read Status
Figure 3.6 General Zone Screen - Read Status
Display
Lines 1 through 7 - Refer to the descriptions in Section 3.2, “Smoke Detector”, on page 40.
Line 15 - the current time and date
3.7 Logic Zone
When a logic zone address is entered into the Point Select Screen and the ACCEPT soft key is
pressed, the following screen will display:
Figure 3.7 Logic Zone Screen - Read Status
Display
Lines 1 through 6 - Refer to the descriptions in Section 3.2, “Smoke Detector”, on page 40.
EQUATION: The logic equation for this logic zone is displayed here
Line 15 - Current time and date.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A FRI SEP 23, 2005
READ ADDRESS: N124Z066
AUTOMATIC INACTIVE
66TH FLOOR Z066
10:22:34A FRI SEP 23, 2005
BACK
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A FRI SEP 23, 2005
READ ADDRESS: N124ZL0066
AUTOMATIC INACTIVE
LOGIC ZONE NUMBER 66 ZL0066
EQUATION:
AND(L1D1,L2D1)
10:22:34A FRI SEP 23, 2005
BACK
