Special Function Zone Read Status
3.9 Special Function Zone
When a special function zone address is entered into the Point Select Screen and the ACCEPT soft
key is pressed, the following screen will display:
Figure 3.9 Special Function Zone Screen - Read Status
Display
Lines 1 through 6 - Refer to the descriptions in Section 3.2, “Smoke Detector”, on page 40.
Line 7 - The special zone number and function is displayed here.
3.10 Trouble Zone
When a trouble zone address is entered into the Point Select Screen and the ACCEPT soft key is
pressed, the following screen will display:
Figure 3.10 Trouble Zone Screen - Read Status
Display
Lines 1 through 6 - Refer to the descriptions in Section 3.2, “Smoke Detector”, on page 40.
EQUATION: The equation for this trouble zone is displayed here.
Line 15 - Current time and date.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A FRI SEP 23, 2005
READ ADDRESS: N124ZF03
AUTOMATIC INACTIVE
SPECIAL ZONE NUMBER 03 ZF03
SECURITY
BACK
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A FRI SEP 23, 2005
READ ADDRESS: N124ZT008
AUTOMATIC INACTIVE
TROUBLE ZONE NUMBER 008 ZT008
EQUATION:
AND(T15,T16)
10:22:34A FRI SEP 23, 2005
BACK
