How Releasing Zones Operate Releasing Zones
Cross=ZONE
An alarm from two detectors mapped to different Software Zones, but
mapped to the same Releasing Zone.
• An alarm from L02D101 and L02D103 – detectors mapped to
different zones, but both list ZR01 in their zone map.
• An alarm from L02D102 and L02D104 – detectors mapped to
different zones, but both list ZR01 in their zone map.
• An alarm from L02D101 and L02D104 – detectors mapped to
different zones, but both list ZR01 in their zone map.
• An alarm from L02D102 and L02D103 – detectors mapped to
different zones, but both list ZR01 in their zone map.
Cross=HEAT
Activation of heat detector L02D104 and one smoke detector
(L02D101, L02D102, or L02D103).
Cross Zone Selection
(Cross=)
Condition(s) Required to Activate the Releasing zone
Table B.2 Example of Cross Zone Selections
To Next Page
