76 NFS2-640 Operations P/N 52743:L4 06/10/19
Point and System Troubles Lists System Troubles
D.2 System Troubles
A message from the “Trouble Type” column in the following table will appear in the panel display
when a system trouble occurs. Use this table to help determine the cause of the trouble.
PRLOSS The output module or new sounder base lost power. Turn power back on.
SHORT The module device has a short circuit on its supervised wiring. Check the connections from the module to the input or
output device to which it is wired.
SHORT ON x
. There is a short on speaker circuit x. Locate the short and fix.
TEST F This detector has failed the FACP’s periodic detector test for alarm
capabilities.
The detector should be removed and replaced by an
authorized service representative.
THERM The thermistors are not functioning properly on an FSC-851 IntelliQuad
detector. (This trouble generates in FlashScan mode only. CLIP mode
will generate a LO VAL error.)
Replace the detector.
VER HI This detector, which has been programmed to participate in alarm
verification, has gone into and come out of verification its programmed
limit without going into alarm. Either something is wrong with the
detector or there is a condition nearby (such as someone smoking) that
causes it to go into verification frequently.
Check the detector and the nearby conditions to
determine the problem.
XP TBL XPIQ general trouble. Check the XPIQ point for problems.
* This trouble may be fire panel or backup battery related. Test and replace backup batteries if necessary.
POINT TROUBLES
TROUBLE TYPE TROUBLE DESCRIPTION ACTION
Table D.1 Point (Device) Troubles (2 of 2)
SYSTEM TROUBLES
TROUBLE MESSAGE
TYPE
TROUBLE DESCRIPTION ACTION
AC FAIL The main power supply has lost AC power. Investigate whether there is an AC power loss, or
whether the PS is correctly installed and wired.
ADV WALK TEST There is an Advanced Walk Test in progress. No action is required.
ANNUN x NO ANSWER The annunciator at address x is not responding. Determine whether the device is functional, and
connected and addressed properly.
ANNUN x TROUBLE The annunciator at address x is in trouble. Determine if the ACS module is functional, correctly
installed, and configured properly.
AUXILIARY TROUBLE An auxiliary device connected to the CPU2-640 at J6 is in
trouble or the cable is missing.
Check the wiring and source.
BASIC WALK TEST A Basic Walk Test is in progress. No action is required.
BATTERY The main power supply’s battery charge is too high or too
low.
Check batteries, replace if necessary.
BAT.BACKUP RAM RAM battery backup is low. Replace battery.
CHARGER FAIL* The main power supply’s battery charger is not working
properly.
Correct the fault.
CORRUPT LOGIC EQUAT The database that houses the panel’s logic equations is
corrupt.
The database must be re-downloaded, or all
programming must be cleared and re-entered.
DRILL ACTIVATED Drill has been activated. No action is required.
DVC ANALOG OUT x TBL A trouble has occurred on DVC-AO analog output x (1-4).
The analog output is configured for class X, but no audio
signal is returned.
Investigate and fix.
DVC AUDIO LIB. CORRUP
The audio library is corrupt.
The library must be re-downloaded, or all
programming must be cleared and re-entered. If the
trouble still does not clear, contact Technical Services.
DVC AUDIO LIB. INCOMP
The audio library is not compatible with the
programming database.
Check the version using VeriFire Tools. Correct
and re-download the database and audio library.
DVC BUZZER OFF-LINE The piezo is disabled. Re-enable the piezo at switch 5 on the DVC.
DVC DAA DOWNLOADING A DAA download is in progress. No action is required.
DVC DATABASE CORRUPT The database that houses the DVC’s programming is
corrupt.
The database must be re-downloaded, or all
programming must be cleared and re-entered. If the
trouble still does not clear, contact Technical Services.
Table D.2 System Troubles
