Section 6. System Programming
6–39
P1 P2 Relay Type Description
18 58 Key Tamper, mom. Sec By partition, if 21 keys are entered without a valid code, keypad tamper
activates momentarily for the number of seconds programmed for that
partition.
19 59 Duress Code, mom. Sec By partition, momentary output based on Seconds. Activated when user
codes 31–32 are enabled for duress (ambush).
1A 5A Bell Strobe - Internal, No
dings
On with either fire or burg, off with code.
1B 5B Bell Strobe - External, with
dings
With arm/disarm dings. Latches on with either a fire or burg bell, off with
code.
1C 5C Trigger Zone, mom Minutes Follows the zone type - trigger. Momentary based on minutes.
1D 5D Trigger Zone, mom. Seconds Follows the zone type - trigger. Momentary based on seconds.
1E 5E Door Strike, mom. Seconds Activates for seconds upon valid user code or user code 20–30 as enabled
in installer programming.
1F 5F Shock Reset (*) Seconds Momentary trigger for seconds when the “*” key is pressed.
20 60 CS Test Momentary Secs. Momentary second trigger, when CS test transmits to CS.
21 61 Alarm/Restore by partition By partition, goes on with alarm and off when all zones for the partition
have met their restore requirements.
22 n/a 2-way voice, on after seize
rel.
Works in conjunction with a two way voice module. The trigger activates
after the dialer is done for the minutes programmed for partition 1. The
keypad sounders are silenced until either bell cut-off or a valid user code is
entered.
23 63 Momentary by Seconds
(fob, soft)
May be activated by keyfobs or soft keys if programmed.
24 64 Momentary by Minutes
(fob, soft)
May be activated by keyfobs or soft keys if programmed.
25 65 Toggle (Keyfob, softkeys) May be activated by keyfobs or soft keys if programmed.
26 n/a Follows Zn Loop, Trig=Zn 1–
20
For the first 20 zones only. The trigger offset is equal to the zone number.
Example trigger 2 follows the normal/off normal state of zone 2.
27 n/a Follows Zn Loop, Trig=Zn 21–
24
Same as type 26, but for zones/triggers 21–24
28 n/a Zone alarm - zones 1–20 Zones 1–20 = triggers 1–20. On with zone alarm, off when alarm memory
is cleared.
29 n/a Zone alarm - zones 21–24 Zones 21–24 = triggers 1–4. On with zone alarm, off when alarm memory
is cleared.
2A n/a Zone alarm restore - zones 1–
20
Zones 1–20 = triggers 1–20. On with zone alarm, off when restore for zone
occurs. This is based on Restore Follows Loop option.
2B n/a Zone alarm restore - zones
21–24
Zones 21–24 = triggers 1–4. On with zone alarm, off when restore for zone
occurs. This is based on Restore Follows Loop option.
2C n/a Sys Bell, Internal (no Dings) Follows bell output but does not respond to bell test.
2D n/a Sys Bell, External (with Dings) Follows bell output, but responds to bell test.
2E 6E RF Jam Activates while an RF Jam condition exists.
2F n/a Keypad Tamper Activates while a Keypad Tamper condition exists.
30 70 24- Hour Silent Zone Activates while a 24-hour silent zone is tripped.
NOTE: In the above table, P1 types 26 through 2B may only be assigned for relays and cannot be
assigned for triggers. Additionally, the relay number to which you assign the type correlates to a
corresponding zone number. For example:
a. If type 28 is assigned to relay 1, relay 1 is energized by an alarm condition on zone 1.
b. If type 28 is assigned to relay 3, relay 3 is energized by an alarm condition on zone 3.
