OMNI624 Installation and Setup Guide
6–40
c. If type 29 is assigned to relay 1, relay 1 is energized by an alarm condition on zone 21.
Q 32 RELAY 1 and 2 TYPES Q 33 RELAY 3 and 4 TYPES
Relay 1 Relay 2 Relay 3 Relay 4
Q 34 RELAY 5 and 6 TYPES Q 35 RELAY 7 and 8 TYPES
Relay 5 Relay 6 Relay 7 Relay 8
Q 36 RELAY 9 and 10 TYPES Q 37 RELAY 11 and 12 TYPES
Relay 9 Relay 10 Relay 11 Relay 12
Q 38 RELAY 13 and 14 TYPES Q 39 RELAY 15 and 16 TYPES
Relay 13 Relay 14 Relay 15 Relay 16
Q 40 RELAY 17 and 18 TYPES Q 41 RELAY 19 and 20 TYPES
Relay 17 Relay 18 Relay 19 Relay 20
Q 42 TRIGGER 1 and 2 TYPES Q 43 TRIGGER 3 and 4 TYPES
Trigger 1 Trigger 2 Trigger 3 Trigger 4
QUESTIONS 44–45 KEYPAD MAPPING
During initial installation, the system reads the addresses of the connected keypads and automatically
maps those keypads to partition 1, therefore, programming of Questions 44–45 is unnecessary. Simply
use the #0 quick command to assign each keypad to the appropriate partition.
IMPORTANT: Make sure keypads of the same type have been set to unique addresses. See Keypad
Addressing paragraph in section 5 for details on setting the keypad addresses.
Once a keypad’s partition assignment has been changed (using the #0 command), the following
questions can be used to enable/disable keypad addresses.
NOTE: LCD = OMNI-LCD*, OMNI-LCD-US*, or XK7LC**; Non-LCD = OMNI-KP* or OMNI-KP-US*
* addressable via keypad programming; ** addressable via DIP switches
