19 69-2805ES—03
Instalación del termostato
Clave para cableado alternativo (sistema de bomba de calor únicamente)
Deje el puente de metal que se encuentra entre los terminales R y RC en el lugar.
Si su termostato existente tenía cables V y VR, visite wifithermostat.com para obtener ayuda.
Si su termostato existente tenía cables O y B separados, conecte el cable B al terminal C. Si se
conecta otro cable al terminal C, visite wifithermostat.com para obtener ayuda. Conecte el cable
O al terminal O/B. Configure la función del sistema 0190 a 0 (consulte la página 55).
Si su termostato existente tenía un cable O en lugar de un cable B, conecte el cable O al
terminal O/B.
Si el termostato existe tenía cables Y1, W1 y W2 separados, visite wifithermostat.com para
obtener ayuda.
Este es el monitor del sistema. Si el monitor detecta un problema, usted verá una luz roja en la
esquina superior derecha del termostato (se ilumina a través de la cubierta).
Si el termostato existente tiene cables separados en AUX y E, coloque los dos cables en el
terminal E/AUX. Si el termostato existente tiene un cable en AUX con un puente conectado a
E, coloque el cable en el terminal E/AUX. No necesita un puente.
No utilice el terminal K. Para uso futuro.
2
3
1
4
5
6
7
