4. Using Telecommunication Function
ScanPal EDA50 Enterprise Hybrid Device User Guide 47
5. Insert SIM card to SIM card slot until it clicks;
6. Insert the battery (Insert the non-connector side first, then press the battery
down to establish connection between the battery and the phone)
7. Press down the battery cover (Insert the connector side first, then press the
battery cover down);
8. Press down the battery cover safety button to move the battery cover safety
lock to the lock position at left;
9. Turn on the terminal.
Making a call
After the phone is successfully activated, you can make calls.
1. Tap in the main interface or application interface.
If the screen shows the list of numbers instead of a dial keypad, tap to
get back to the dial keypad.
2. Tap the keys to enter the numbers, and then tap the below the keys to
make the call after all numbers have been entered.
3. To end the call, tap .
