14 General specication
Sensepoint XCD Transmitter
Use 3-wire, 4-20mA, gas detector transmitter for use with remotely mounted ammable gas
detectors.
Electrical
Input Voltage Range:
Max Power Consumption:
Current output
≥0.0<1.0 mA
4.0 mA to 20.0 mA
2.0 mA or 4.0 mA
22.0 mA
Terminals
Relays
Communication
12 to 32Vdc (24Vdc nominal)
Max 5 Watts. at 24Vdc (see section 2 regarding maximum in
rush current)
4-20mA (Source or Sink)
Fault (refer to table 5 section 12.3 for further details)
Normal gas measurement
Inhibit (during conguration/user settings)
Maximum over range
15 x screw terminals suitable for wire diameter 0.5mm
2
to
2.5mm
2
(20AWG to 13AWG).
3 x 5A@250VAC. Selectable normally open or normally closed
(switch) and energized/de-energized (programmable).
RS485, Modbus RTU
Construction
Material Epoxy painted aluminium alloy or 316 Stainless Steel
Weight Aluminium alloy: 1.7kg, 316 Stainless Steel: 3.7kg
Mounting Pole or wall mounting
Cable Entries 2 x M20 (for ATEX/IECEx/AP Approval) , or 2 x 3/4"NPT (for cCSAus Approval)
Sensor Entry M25 (for ATEX/IECEx/AP Approval) or 3/4"NPT (for cCSAus Approval)
Detectable Gases & Performance (See notes below)
Gas Selectable Full
Scale Range
Default
Range
Steps Selectable
Cal Gas
Range
Default
Cal
Point
Response
Time (T60)
Secs
Response
Time (T90)
Secs
Accuracy Operating Temperature Default Alarm Points
Min Max A1 A2
Sensepoint Standard Temperature Sensor
25 to 95% of
selected full
scale range
Flammable 1 to 8* 20 to 100%LEL 100%LEL 10%LEL 50%LEL <25 <+/- 1.5%LEL -55°C / -67°F 80°C / 176°F 20%LEL▲ 40%LEL▲
Sensepoint High Temperature Sensor
Flammable 1 to 8* 20%LEL 20%LEL n/a 10%LEL <25 <+/- 1.5%LEL -55°C / -67°F 150°C / 302°F 10%LEL▲ 15%LEL▲
Flammable 1 to 8* 20 to 100%LEL 100%LEL 10%LEL 50%LEL <10 <+/- 1.5%LEL -55°C / -67°F 150°C / 302°F 20%LEL▲ 40%LEL▲
Plug-in Sensepoint XCD Catalytic Bead Sensors
Flammable 1 to 8* * 20 to 100%LEL 100%LEL 10%LEL 50%LEL <6 <25 <+/- 1.5%LEL -20°C / -4°F 55°C / 131°F 20%LEL▲ 40%LEL▲
Plug-in Sensepoint XCD Infrared Sensors
30 to 70% of
selected full
scale range
Methane 20 to 100%LEL 100%LEL 10%LEL 50%LEL <40 <+/- 1.5%LEL -20°C / -4°F 50°C / 122°F 20%LEL▲ 40%LEL▲
Propane* 20 to 100%LEL 100%LEL 10%LEL 50%LEL <40 <+/- 1.5%LEL -20°C / -4°F 50°C / 122°F 20%LEL▲ 40%LEL▲
Carbon Dioxide* 2.00%Vol 2.00%Vol. n/a 1.00%Vol. <40 <+/-0.04%Vol. -20°C / -4°F 50°C / 122°F 0.40%V/V.▲ 0.80%V/V.▲
*Contact Honeywell Analytics for availability ▲ - Rising Alarm ▼ - Falling Alarm
NOTES
Performance gures are taken at 20-25°C;
1. measured using a sample humidity of 50%RH, applicable between 10 and 90% of full scale,
2. measured using test units calibrated at 50% of full scale,
3. measured at 1000cc/min for Methane CAT, 500cc/min for Methane IR with calibration cup (S3KCAL).
Response time (T90) may increase when operating in lower or higher temperature conditions or when gas is introduced with the Weather Protection accessory (SPXCDWP) tted. Methane IR
sensor is calibrated and linearised only for Methane. Should it be exposed to other HC then non linear response is expected. For linearised operation other than Methane contact HA for alternate
parts.
Methane IR is calibrated at the factory 50%LEL Methane (2.5%Vol). This calibration enables 100% functional test prior to dispatch. This calibration does not remove need for calibration & test as
part of commissioning at site. For gases other than Methane the unit has to be calibrated at site using target gas.Data represents typical values, and system conditioning may be required to achieve
stated result.
Contact HA for details.
* Extended operating temperature range of -40°C to +65°C (-40°F to +149°F) for all sensor except for IR, with an accuracy of +/- 30% of applied gas from -20°C to -40°C (-4°F to -40°F) and
+55°C to +65°C (+131°F to +149°F). Long term operation at this range may cause decline in sensor performance.
Contact Honeywell Analytics for any additional data or details.
Certication
China GB Ex d IIC T4 GB3836.1&2 -2000, PA, CCCF
Korea KTL Ex d IIC T6 (-40ºC to +65ºC)
European ATEX Ex II 2 GD Ex d IIC Gb T6(Ta -40ºC to +65ºC) Ex tb IIIC T85ºC Db IP66
International IEC Ex II 2 GD Ex d IIC Gb T6(Ta -40ºC to +65ºC) Ex tb IIIC T85ºC Db IP66
North America
cCSAus Class I, Division 1, Groups B, C & D/ Flammable Performance CSA C22.2 No.152 and ISA 60079-29-1(Only combustion gas detection portion of the instrument has been assessed)
CE EN50270:2015 EN6100-6-4:2007
Environmental
IP Rating IP66 in accordance with EN60529:1992, NEMA 4X (Tested by third party laboratory)
Operating Temperature -40ºC to +65ºC/ -40ºF to +149ºF, (IR: -20ºC to +50ºC/ -4ºF to +122ºF)
Note: The detector display may become illegible at temperatures below -20°C, but the detector continues its gas monitoring
function. The display is not damaged and recovers when the temperature rises back above -20 °C.
Operating Humidity Continuous 20-90%RH (non condensing), Intermittent 10-99%RH (non condensing)
Operating Pressure 90-110kPa
Storage Conditions -25°C to +65°C (-13°F to +149°F)
