Specications
Install TrueDRY DR65 according to National Electric Codes.
Dimensions in inches and (mm):
Product weight: 55 lb (25 kg)
Shipping weight: 65 lb (30 kg)
Shipping dimensions: 17 ¼ in. H x 15 ½ in. W
x 31 ½ in. L
Media Filter: MERV 11, 9 in. H x 11 in. W x 1 in. D
Drain connection: 3/4-in. threaded female NPT
connection.
Duct connections: 8-in. round inlet and outlet. ABS
plastic, compatible for connection to rigid or flexible
ducting with sheet metal screws and/or tape.
Cabinet: 18 gauge galvanized steel powder-coat
painted.
Insulation: R value 1
Compressor: Rotary-style, 5.8 KBTU
Refrigerant: R-410A, 15 oz.
Operating Temp Range (outside cabinet):
34ºF to 135ºF (1.1ºC to 57.2ºC)
Operating Humidity Range: 0-99% RH
Input ratings
• Electrical input voltage: 120 VAC, 60 Hz
nominal
• Input current: 5.2 A
Output ratings
• Power transformer to R/C terminals: 24
VAC, 0.85 A
• Energy Performance: 2.22 liters (4.7 pints)
per kilowatt hour (KWH)
Standards and approval body
requirements
ETL Tested per standard UL 60335-2-40
ducted dehumidifier.
ENERGY STAR rated.
Dry-Bulb Temp Intake Humidity Capacity (Pints/Day)
80°F (26.7°C) 60% RH 68
70°F (21.1°C) 60% RH 47
60°F (15.6°C) 60% RH 34
Home Size
(square ft) @
8 ft ceiling
Dehumidifier Capacity Required to Maintain Desired Indoor RH*
60% RH Indoor
(pints/day)
50% RH Indoor
(pints/day)
40% RH Indoor
(pints/day)
2080 49–54 55–58 71–78
2600 61–68 65–72 90–97
3120 75–82 79–86 95–110
* Based on extreme climates where outdoor humidity is 70-90% RH. For less extreme climates, larger
homes can be adequately served with less capacity. Actual requirements may vary.
Airflow versus external static pressure
(0–1 in. water pressure) with collars
attached
0 in. 160 CFM
0.2 in. 140 CFM
0.4 in. 120 CFM
0.6 in. 100 CFM
M29763
12
8 INCH (203)
DIAMETER
TrueDRY™ DR65 Dehumidication System 69-2089EFS—14
