Humidier
NEED HELP? For assistance with this product please visit http://yourhome.honeywell.com
or call Honeywell Customer Care toll-free at 1-800-468-1502.
Read and save these instructions.
® U.S. Registered Trademark. Patents pending. Copyright © 2014 Honeywell International Inc. All rights reserved.
?
Humidier 33-00067EF—01
GETTING
STARTED
MOUNTING PLUMBING WIRING APPENDICES
OPERATION
AND SERVICE
1
GETTING STARTED
Safety Denitions and Precautions .............. 2
What to Expect From Your Humidier ............ 3
Important Installation Requirements ............. 4
MOUNTING
Choosing a Mounting Method .................. 5
STEP ONE: Select the Mounting Location ...... 6
STEP TWO: Install Mounting
Template to the Duct .................... 6
Bypass Model Installation ..................... 7
STEP THREE: Congure
Humidier Bypass ...................... 7
STEP FOUR: Installation ................... 8
STEP FIVE: Bypass Duct Installation ......... 9
PLUMBING
Water Supply and Drain Connections ........... 10
STEP ONE: Connect the Water Supply ....... 10
STEP TWO: Tap into a Water Line ........... 10
STEP THREE: Connect to the Water Drain .... 11
WIRING
Before Wiring Humidier ..................... 12
STEP ONE: Remove the Humidier Cover .... 12
STEP TWO: Install the Transformer
(Bypass Models Only) .................. 12
STEP THREE: Wiring Humidier ............ 12
Installing the Humidistat ..................... 13
Duct Installation (H8908) ................13-14
Remote Installation (H8908) ................ 14
Humidistat Wiring ......................15-17
Humidistat Checkout ..................... 18
Humidistat Operation ..................... 18
OPERATION AND SERVICE
Startup and Checkout ....................... 19
Routine Maintenance ........................ 20
Troubleshooting ............................ 21
APPENDICES
A: Specications ........................... 22
B: Advanced Draining ....................... 23
C: Parts List .............................24-25
