Honeywell TrueEASE Professional Installation Guide

MOUNTING
Before proceeding to the next step:
I secured the humidier to the duct as instructed.
Bypass Model Installation
Humidier 33-00067EF—01
9
STEP FIVE: Bypass Duct Installation
On the duct opposite the humidier Bypass install, cut
a 6-in. diameter duct hole.
• If the humidier is on the supply duct, the 6-in.
diameter hole should be on the return.
• If the humidier is on the return duct, the 6-in.
diameter hole should be on the supply.
Secure a 6-in. round duct starter collar into the 6-in.
duct hole.
Use rigid or aluminized exible 6-in. duct to connect
the starter collar to the humidier bypass port.
Secure the duct to the humidier port with self-drilling
sheet metal screws using the pre-drilled holes on the
bypass port. For added seal, wrap sheet metal tape
around the duct to port connection point.
MCR29933
MCR29878
2
2
2
1
1
