UDC 1200 Start-Up Guide Rev 1
Parameter
Lower
Display
Upper
Display
Adjustment range
Default
Primary Output
Control Action


Reverse Acting


Direct Acting
Alarm 1Type


Process High Alarm


Process Low Alarm

Deviation Alarm

Band Alarm

No alarm
High Alm 1 value*

Range Min. to Range Max
in display units
Range Max.
Low Alm 1 value*

Range Min.
Band Alm 1 value*

1 LSD to span from setpoint in display units

Dev. Alm 1 value*

+/- Span from setpoint in display units

Alm 1 Hysteresis*

1 LSD to full span in display units

Alarm 2 Type*

Options as for alarm 1

High Alm 2 value*

Range Max.
Low Alm 2 value*

Range Min.
Band Alm 2 value*


Dev. Alm 2 Value*


Alm 2 Hysteresis*


Loop Alarm

(disabled) or  (enabled)

Loop Alarm Time*

1 sec to 99 mins. 59secs
(only applies if primary proportional band = 0)
.
Alarm Inhibit


No alarms Inhibited


Alarm 1 inhibited

Alarm 2 inhibited

Alarm 1 and alarm 2 inhibited
Output 1 Usage


Primary (Heat) Power


Secondary (Cool) Power

Alarm 1, Direct

Alarm 1, Reverse

Alarm 2, Direct

Alarm 2, Reverse

Loop Alarm, Direct

Loop Alarm, Reverse

Logical Alarm 1 OR 2, Direct

Logical Alarm 1 OR 2, Reverse

Logical Alarm 1 AND 2, Direct

Logical Alarm 1 AND 2, Reverse

Retransmit SP Output

Retransmit PV Output
Linear Output 1
Range


0 – 5 V DC output 1


0 – 10 V DC output

2 – 10 V DC output

0 – 20 mA DC output

4 – 20 mA DC output
