Honeywell XENON 1902

11 - 42
Image Ship
(continued)
Invert Image around
X axis
IMGNVX1 8-8
Invert Image around
Y axis
IMGNVY1 8-8
Rotate Image none IMGROT0 8-9
Rotate Image 90°
right
IMGROT1 8-9
Rotate Image 180°
right
IMGROT2 8-9
Rotate Image 90°
left
IMGROT3 8-9
JPEG Image Quality
(0-100) *50
IMGJQF### 8-10
*Gamma Correction
Off
IMGGAM0 8-10
Gamma Correction
On (0-1000)
IMGGAM### 8-10
Image Crop - Left (0-
843) *0
IMGWNL### 8-10
Image Crop - Right
(0-843) *843
IMGWNR### 8-10
Image Crop - Top (0-
639) *0
IMGWNT### 8-10
Image Crop -
Bottom (0-639) *639
IMGWNB### 8-11
Image Crop - Margin
(1-238) *0
IMGMAR### 8-11
Protocol - None
(raw)
IMGXFR0 8-11
Protocol - None
(default USB)
IMGXFR2 8-11
Protocol - Hmodem
Compressed
IMGXFR3 8-11
Protocol - Hmodem IMGXFR4 8-11
Ship Every Pixel IMGSUB1 8-12
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric
entry
Page
