Honeywell XENON 1902

3 - 8
Scanner LED Sequences and Meaning
Base/Access Point LED Sequences and Meaning
The base contains a red LED and the Access Point has a blue LED that
indicate the status of the unit and verifies its communication with the host
system. The base also has a green LED that indicates scanner battery
charge condition.
LED
Indication
Beeper
Indication
Vibrate
Indication
Cause
Normal
Operation
Red Flash None None Battery low
Green Flash 1 beep None Successful
communication or
linking
Red, blinking Razz or error
tone
None Failed communication
Menu
Operation
Green Flash 2 beeps 2 vibrations Successful menu
change
Red, blinking Razz or error
tone
1 long
vibration
Unsuccessful menu
change
Red or Blue LED - Host Communication
Red or Blue LED Communication Condition
Off USB suspend
On continuously Power on, system idle
Short blinks in multiple pulses. Occurs
while transferring data to/from the RF
module or the Host port.
Receiving data
