Honeywell XENON 1902

12 - 4
Granit 1911i Industrial Cordless Scanner Product
Specifications
Pitch Angle +45°
Motion Tolerance:
Streaming Presentation Trigger:
13 mil UPC
240 inches per second at 6.5 in. (16.5cm)
150 inches per second at 10 in. (25.4cm)
Symbol Contrast Grade 1.0 (20% or greater)
Voltage Requirements
4 - 5.5 VDC at input connector
Current Draw @5VDC
Scanning
Standby
470mA, 2.35W 100mA, .5W
Power Supply Noise Rejection Maximum 100mV peak to peak, 10 to 100 kHz
Temperature Ranges:
Operating
-22°F to +122°F (-30°C to 50°C)
Storage
-40°F to +158°F (-40°C to 70°C)
Humidity 0 to 95% non-condensing
Mechanical Drop
Operational after 50 drops from 6.5 feet
(1.98m) to concrete at 23°, -30°, and 50°C
Vibration
Complies with MIL-STD-810G, Method 514.6, Annex
C
ESD Tolerance
Up to 20kV direct air
Up to 8 kV indirect coupling plane
Sealant Rating IP65
Parameter Specification
Dimensions (Typical):
Height
7.7 in. (19.45cm)
Length
5.2 in. (13.31cm)
Width
2.9 in. (7.5cm)
Weight
12.9 oz. (365g)
Illumination LED:
Peak Wavelength
656nm (hyper red LED)
IEC 62471: “Exempt Risk Group”
Aiming:
Peak Wavelength Laser
650nm
IEC 60825-1: “Class 2”
Optical Power Laser
<1mW
Parameter Specification
