1 - 4
base sits flat on a horizontal surface. If you are connecting a CCB02-
100BT Base, see Mounting a CCB02-100BT Base on page 1-11.
4. The scanner beeps.
5. Verify the scanner or cordless base operation by scanning a bar code
from the Sample Symbols in the back of this manual.
The unit defaults to a USB PC Keyboard. Refer to page 2-4 for other USB
terminal settings.
For additional USB programming and technical information, refer to “USB
Application Note,” available at www.honeywellaidc.com.
Connecting with Keyboard Wedge
A scanner or cordless base can be connected between the keyboard and
PC as a “keyboard wedge,” where the scanner provides data output that is
similar to keyboard entries. The following is an example of a keyboard
wedge connection:
1. Turn off power and disconnect the keyboard cable from the back of the
terminal/computer.
2. Connect the appropriate interface cable to the device and to the
terminal/computer.
Corded Xenon Scanner
Keyboard Wedge
Connection:
To Next Page
