12 - 7
CCB02-100BT Industrial Charge Base Product
Specifications
Parameter Specification
Dimensions (Typical):
Height
2.6 in. (6.6cm)
Length
9.8 in. (24.98mm)
Width
4.05 in. (10.28cm)
Weight
10.05 oz. (285g)
Voltage: 4.5 to 5.5 volts
Current Draw:
Host Terminal Port
500mA
Aux Power Port
1A
Charge Time 5 hours
Radio:
Frequency
2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.2.1
Range
330 ft. (100m) typical
Data Rate
Up to 1 MBps
Temperature Ranges:
Operating
-4° F to +122° F (-20° C to +50° C)
Battery Charge
41° F to +104° F (5° C to +40° C)
Storage
-40° F to +158° F (-40° C to +70° C)
Humidity
Up to 95% non-condensing
Mechanical Drop
Operational after 50 drops from 3.94 feet
(1.2m) to concrete
Vibration
Complies with MIL-STD-810G, Method 514.6, Annex
C
ESD Sensitivity
Up to 20kV direct air
Up to 8 kV indirect coupling plane
