Honeywell XENON 1902G-BF - Chapter 13 - Product Specifications; Xenon 1900;1900 h;1910 Corded Scanner Product Specifications

CHAPTER
13
Xenon/Granit User Guide 295
PRODUCT SPECIFICATIONS
Xenon 1900/1900h/1910 Corded Scanner Product
Specifications
Parameter Specification
Mechanical
Height 6.3 inches (160mm)
Length 4.1 inches (104.1mm)
Width 2.8 inches (71.1mm)
Weight 5.2 ounces (147.42g)
Electrical
Voltage Requirements 4 - 5.5 VDC at input connector
Current Draw @5VDC
B&W
Color
ScanningStandby
470mA, 2.35W90mA, .45W
490mA, 2.45W90mA, .45W
Power Supply Noise Rejection Maximum 100mV peak to peak, 10 to 100 kHz
Illumination LED:
Peak Wavelength 624nm + 18nm (red LED)
IEC 62471: “Exempt Risk Group”
442nm, 552nm (white LED)
IEC 62471: “Exempt Risk Group”
Aiming:
Peak Wavelength Laser 650nm
IEC 60825-1: “Class 2”
Peak Wavelength LED 624nm +
18nm (red LED)
520nm +
18nm (green LED)
IEC 62471: “Exempt Risk Group”
Optical Power Laser <1mW
Environmental
Temperature Ranges:
Operating +32F to +122F (0C to 50C)
